Prefabricated philippines temporary dormitory homes house kit with sandwich panel

FOB Reference Price:Get Latest Price
US $1,500-2,600 / Sets | 6 Set/Sets two storey modular kit house (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shanghai, China (Mainland)
Brand Name:
ALLSTAR
Model Number:
ZGM
Material:
Container, steel structure + sandwich
Use:
Carport, Hotel, House, Kiosk,Booth, Office, Sentry Box,Guard House, Shop, Toilet, Warehouse, Workshop,Plant
Column:
2.5mm glavnized
Floor:
Vinyl Sheet on Plywood
Window:
Aluminum or PVC Frame with Clear Glass
Structure:
Galvanized Steel Frame
Fire Proof:
B1 grade
Beam:
2.5mm galvanized purline
Steel frame:
made from cold rolled
Insulation:
50 mm thick Rock Wool
Ceiling:
10 mm chipboard (V 20), laminated on both sides
Supply Ability
Supply Ability:
300 Set/Sets per Month two storey modular kit house
Packaging & Delivery
Packaging Details
A 40 HQ shipping Container House can hold in 6 sets container house
Port
shanghai
Lead Time :
Shipped in 30 days after payment




 Dimension(mm)&Weight(kg) of Prefabricated philippines temporary dormitory homes house kit with sandwich panel

 color steel type details



Type

External

Internal

Weight (kg)

Length

Width

Height (package)

Height (assembled)

Length

Width

Height

20'

6000

2550

648/864

2550/2700

5800

2400

2500

from 1800



Floor

Steel frame

- made from cold rolled, welded steel profiles, 4 mm thick

- 4 corner casts, welded

- 2 fork lift pockets (except 30') - distance 1200mm

(internal clearance of fork lift pockets: 240×80 mm)

- steel cross members, thickness=2mm

Insulation

- 100 mm thick Rock Wool

Subfloor

- 0.5mm thick, galvanized steel sheet

Floor

- 18mm plywood board

- 1.8mm PVC floor

- flammability class B1 - hardly combustible

- smoke density class Q1 - low smoke emission

- wear resistance factor: T level



Roof

Steel frame

- made from cold rolled, welded steel profiles, 3mm thick

- 4 corner casts, welded

- steel cross members, thickness=2mm

Roof cover

- 0.5mm thick, galvanized steel sheet

- 360 degree seaming at joint of roof panels

Insulation

- 100 mm thick Rock Wool

Ceiling

- 10 mm chipboard (V 20), laminated on both sides, white

- the chipboard complies with the emission value E1

CEE connector

- sunken in frame on short end side



Advantages

1. All Size Available: Regular or unusual

2 Cooperative Partners: All kinds of steel mails(state-owned, medium, small size) with all level products

3. Mature Teamwork: Complete and orderly team structure, including rich-experienced leader and energetic fresh blood

4. Export Ability: Having good exporting ability and relative exporting qualifications

5. Reasonable Price: Able to give you best price

6. Multiple Payment Terms: T/T, T/T and L/C, T/T,etc

7. Delivery: Delivery on time





Our servicces:

If you are interested in our Prefabricated philippines temporary dormitory homes house kit with sandwich panel,please kindly provide to us your prefab house drawings or the following information,

so that we can give you a better offer.

1).Dimension:Length,width,height,roof pitch

2).Doors and windows:dimensions,quantity,the position to fix.

3).Local climate:Wind speed,snow/rain load,earthquake.

4).Insulation materials:sandwich panel or steel sheet.

5).Crane beam:Do you require a crane beam inside you steel structure building?

and what is the capacity?

6).Where does your house plan to use?

7).Are there any materials that are not allowed to import into your country?








 _20170424125252_20170424125324



Interior Layout

 double house ,1

12_07
